Input and Output Channels
INPUTS
Built-in mic (stereo)
1
XLR/TRS
2
MIC/LINE IN
1
OUTPUTS
Headphones
1
Built-in speaker (mono)
1
Inputs
BUILT-IN MIC
90° XY stereo format
Directionality
Unidirectional
Sensitivity
–43 dB/1 Pa at 1 kHz
Maximum sound pressure input
130 dB SPL
XLR/TRS
Connector
XLR/TRS combo jacks ×2
(XLR:2 HOT TRS:TIP HOT)
Input gain
Adjustment unnecessary
Input impedance
XLR : 3 kΩ or more TRS : 3 kΩ or more
Maximum input level
XLR : +4 dBu TRS : +24 dBu
Phantom power
+48 V
Channel total 10 mA or less
Equivalent input noise
-120 dBu or less(IHF-A) @150 Ω input
MIC/LINE IN
Connector
Stereo mini jack ×1
SUPPORTS PLUG-IN POWER)
Input gain
Adjustment unnecessary
Input impedance
2 kΩ or more
Outputs
HEADPHONES
Connector
Stereo mini jack ×1
Maximum output level
20 mW + 20 mW(into 32 Ω load)
Output impedance
15 Ω or less
Recorder
Maximum simultaneous recording tracks
4
Maximum simultaneous playback tracks
4
Recording formats
WAV
44.1/48/96 kHz,
32-bit float mono/stereo
BWF and iXML formats supported
Recording media
4-32GB cards compatible with the
microSDHC specification
64GB–1TB cards compatible with the
microSDXC specification
Display
2.0-inch full-color LCD(360 x 240)
USB
CONNECTOR
USB Type-C
Use a USB cable that supports data transfer.
USB bus power is supported.
USB MIC
USB 2.0 High Speed
44.1/48 kHz
24-bit /32-bit float
4-in/2-out
FILE TRANSFER
USB2.0 High Speed
Remote
Dedicated wireless adapter(ZOOM BTA-1)
Power
4 AA batteries (alkaline, NiMH or lithium)
AC adapter(ZOOM AD-17):DC 5V/1A
USB bus power is supported.
ESTIMATED CONTINUOUS OPERATION TIMES USING BATTERIES
2-track recording (built-in XY mic), 48 kHz/32-bit float, phantom power off, no headphones, no remote, display power saving on
Alkaline batteries: about 9 hours
NiMH batteries (1900 mAh): about 14 hours
Lithium batteries: about 20 hours
POWER CONSUMPTION
3 W maximum
DIMENSIONS
66.9 mm (W) × 156.1 mm (D) × 38.0 mm (H)
WEIGHT (INCLUDING BATTERIES)
226g
