Number of effective pixels
26.1 million pixels
Image sensor
23.5mm x 15.6mm (APS-C)
X-Trans CMOS 4 with primary color filter.
Storage media
SD memory card (~2GB) / SDHC memory card (~32GB) / SDXC memory card (~512GB)
UHS-I / UHS-II / Video Speed Class V90
File format of still image
JPEG: Exif Ver.2.3 *2 : RAW: 14bit RAW (RAF original format) TIFF: 8/16bit RGB
Lens mount
FUJIFILM X Mount
Sensitivity
Standard output: AUTO1 / AUTO2 / AUTO3 (up to ISO12800) / ISO160 to 12800(1/3 step)
Extended output: ISO80 /100 /125 / 25600 / 51200
Exposure control
TTL 256-zone metering, Multi / Spot / Average / Center Weighted
Exposure mode
P (Program AE) / A (Aperture Priority AE) / S (Shutter Speed Priority AE) / M (Manual Exposure)
Exposure compensation
-5.0EV~+5.0EV 1/3EV step (Movie: -2.0EV~+2.0EV)
Image stabilizer
Mechanism: Image sensor shift mechanism with 5-axis compensation
Compensation Effect: Maximum 6.5 stops (based on CIPA standard. Pitch/yaw shake only.
Digital Image Stabilization: Yes (movie mode only)
IS MODE BOOST: Yes (movie mode only)
Shutter type
Focal Plane Shutter
Movie recording
MOV (MPEG-4 AVC/H.264, HEVC/H.265, Audio: Linear PCM / Stereo sound 24bit / 48KHz sampling) MP4 (MPEG-4 AVC/H.264, Audio: AAC)
All Intra/Long-GOP
* All Intra can be used with following settings.
DCI4K/4K 29.97p/25p/24p/23.98p 400Mbps
Full HD(2048×1080)/ Full HD(1920×1080 / 59.94p/50p/29.97p/25p/24p/23.98p 200Mbps
DCI 4K(4096×2160 / 59.94p/50p/29.97p/25p/24p/23.98p / 400Mbps/200Mbps/100Mbps 59.94p/50p: up to approx.
20min. 29.97p/25p/24p/23.98p: up to approx. 30min
4K(3840×2160 / 59.94p/50p/29.97p/25p/24p/23.98p / 400Mbps/200Mbps/100Mbps 59.94p/50p: up to approx. 20min.
29.97p/25p/24p/23.98p: up to approx. 30min
Full HD(2048 ×1080 / 59.94p/50p/29.97p/25p/24p/23.98p / 200Mbps/100Mbps/50Mbps up to approx. 30min.
Full HD(1920×1080 / 59.94p/50p/29.97p/25p/24p/23.98p / 200Mbps/100Mbps/50Mbps up to approx. 30min.
Full HD(1920×1080) High speed rec.]
240p / 200p 200Mbps(recording) up to approx. 3min.
120p / 100p 200Mbps(recording) up to approx. 6min.
*For recording movies, use a SD memory card with UHS Speed Class 3 or higher.
*For recording movies in 400Mbps, use a SD memory card with Video Speed Class 60 or higher.
*Recording movies in 400Mbps can be done with DCI4K/4K 29.97p/25p/24p/23.98p.
*DCI4K 59.94p/50p is not available when H.264 is selected.
*Although movie recording will continue without interruption when the file size reaches 4GB, subsequent footage will be recorded to a separate file which must be viewed separately.
Flash modes
1ST CURTAIN / 2ND CURTAIN / AUTO FP(HSS) (excl. EF-X8)
Sync. Mode: TTL (TTL AUTO (P mode) / STANDARD / SLOW SYNC. ) / MANUAL / COMMANDER / OFF (When EF-X8 is set)
Flash Mode: TTL (TTL AUTO (P mode) / STANDARD / SLOW SYNC. ) / MANUAL / MULTI / OFF (When SHOE MOUNT FLASH is set)
LCD monitor
3.0 inch, aspect ratio 3:2, approx. 1.62 millions dots touch screen color LCD monitor(approx. 100% coverage)
Viewfinder
0.5 inch approx. 3.69 millions dots OLED Color Viewfinder / Coverage of viewing area vs. capturing area: approx. 100%
Eyepoint: approx. 23mm (from the eyepiece lens) Diopter adjustment: -4~+2m-1 (lockable)
Magnification: 0.75× with 50mm lens (35mm equivalent) at infinity and diopter set to -1m-1
Diagonal angle of view: approx. 38° (Horizontal angle of view: approx. 30° ) Built-in eye sensor
Terminal
Digital interface: USB Type-C (USB3.2 Gen1x1)
HDMI output: HDMI micro connector (Type D)
Other: 3.5mm, stereo mini connector (Microphone) / ø2.5mm, Remote Release Connector, Hot shoe, Synchronized terminal
Dimensions
(W) 134.6mm x (H) 92.8mm x (D) 63.8mm (minimum depth 37.9mm)
Weight
Approx. 607g (including battery and SD memory card)
Approx. 526g (excluding battery and SD memory card)
