Recording System (Stills)
Image Size
L: 7008 x 4672 (33 M), M: 4608 x 3072 (14 M), S: 3504 x 2336 (8.2 M)
Image Quality Modes
RAW, JPEG, HEIF (4:2:0 / 4:2:2), RAW & JPEG, RAW & HEIF
14bit RAW
Yes
Recording Format (Still Image)
JPEG (DCF Ver. 2.0, Exif Ver. 2.32, MPF Baseline compliant), HEIF (MPEG-A MIAF compliant), RAW (Sony ARW 5.0 format compliant)
Recording System (Movie)
Video Compression
XAVC HS: MPEG-H HEVC/H.265, XAVC S: MPEG-4 AVC/H.264
Audio Recording Format
LPCM 2ch (48 kHz 16 bit), LPCM 2ch (48 kHz 24 bit), LPCM 4ch (48 kHz 24 bit)
Movie Recording Format (XAVC HS 4K)
3840 x 2160 (4:2:0, 10bit) (Approx.): 59.94p (150 Mbps / 75 Mbps / 45 Mbps), 23.98p (100 Mbps / 50 Mbps / 30 Mbps), 50p (150 Mbps / 75 Mbps / 45 Mbps)
3840 x 2160 (4:2:2, 10bit) (Approx.): 59.94p (200 Mbps / 100 Mbps), 23.98p (100 Mbps / 50 Mbps), 50p (200 Mbps / 100 Mbps)
Movie Recording Format (XAVC S 4K)
3840 x 2160 (4:2:0, 8bit) (Approx.): 59.94p (150 Mbps), 29.97p (100 Mbps / 60 Mbps), 23.98p (100 Mbps / 60 Mbps), 50p (150 Mbps), 25p (100 Mbps / 60 Mbps)
3840 x 2160 (4:2:2, 10bit) (Approx.): 59.94p (200 Mbps), 29.97p (140 Mbps), 23.98p (100 Mbps), 50p (200 Mbps), 25p (140 Mbps)
Movie Recording Format (XAVC S HD)
1920 x 1080 (4:2:0, 8bit) (Approx.): 119.88p (100 Mbps / 60 Mbps), 59.94p (50 Mbps / 25 Mbps), 29.97p (50 Mbps / 16 Mbps), 23.98p (50 Mbps), 100p (100 Mbps / 60 Mbps), 50p (50 Mbps / 25 Mbps), 25p (50 Mbps / 16 Mbps)
1920 x 1080 (4:2:2, 10bit) (Approx.): 59.94p (50 Mbps), 29.97p (50 Mbps), 23.98p (50 Mbps), 50p (50 Mbps), 25p (50 Mbps)
Movie Recording Format (XAVC S-I 4K)
3840 x 2160 (4:2:2, 10bit) (Approx.): 59.94p (600 Mbps), 29.97p (300 Mbps), 23.98p (240 Mbps), 50p (500 Mbps), 25p (250 Mbps)
Movie Recording Format (XAVC S-I DCI4K)
4096 x 2160 (4:2:2, 10bit) (Approx.): 59.94p (600 Mbps), 29.97p (300 Mbps), 23.98p (240 Mbps), 50p (500 Mbps), 25p (250 Mbps), 24.00p (240 Mbps)
Movie Recording Format (XAVC S-I HD)
1920 x 1080 (4:2:2, 10bit) (Approx.): 59.94p (222 Mbps), 29.97p (111 Mbps), 23.98p (89 Mbps), 50p (185 Mbps), 25p (93 Mbps)
Movie Function
Proxy Recording
Yes
TC/UB
Yes
RAW Output
Yes (HDMI)
Slow & Quick Motion (S&Q)
Yes
Memory Card Slot
SLOT1: Multi slot for SD (UHS-I/II compliant) memory card / CFexpress 2 Type A card, SLOT2: SD (UHS-I/II compliant) memory card
Focus System
Type
Fast Hybrid AF (phase-detection AF / contrast-detection AF)
Focus Point
Still images: Max. 759 points (phase-detection AF), Movies: Max. 627 points (phase-detection AF)
Sensitivity Range
EV-4 to EV20 (ISO100 equivalent with F2.0 lens attached)
Other Features
AF Track Sens. (Still), AF Subj. Shift Sensitivity (Movie), AF Transition Speed (Movie), Switch V/H AF Area, AF Area Regist., Circ. of Focus Point, Focus Map (Movie), AF Assist (Movie)
Recognition Target (Still images)
Auto, Human, Animal, Bird, Insect, Car, Train, Airplane
Recognition Target (Movies)
Auto, Human, Animal, Bird, Insect, Car, Train, Airplane
Exposure Control
Metering Sensitivity
EV-3 to EV20 (at ISO100 equivalent with F2.0 lens attached)
Metering Type
1200-zone evaluative metering
Exposure Compensation
+/- 5.0 EV (1/3 EV, 1/2 EV steps selectable)
Anti-Flicker Shoot.
Yes *Anti-flicker Shooting is not available when the [Shutter Type] setting is set to [Electronic Shutter].
ISO Sensitivity
Still images: ISO 100 - 51200 (expandable to ISO 50 - 204800), AUTO (ISO 100 - 12800, selectable lower limit and upper limit) Movies: ISO 100 - 51200 equivalent (expandable to ISO 102400), AUTO (ISO 100 - 12800, selectable lower limit and upper limit)
Viewfinder
Diopter adjustment
-4.0-+3.0 m-1
Type
1.3 cm (0.5 type) electronic viewfinder (Quad-VGA OLED)
Magnification
Approx. 0.70x (with 50 mm lens at infinity, -1 m-1)
Eye Point
Approx. 33 mm from the eyepiece lens, 27 mm from the eyepiece frame at -1 m-1 (CIPA standard)
Number of Dots
3 686 400 dots
Finder Frame Rate Selection
STD 60fps / HI 120fps
LCD Screen
Touch Panel
Yes
Adjustable Angle
Opening Angle: Approx. 176 °, Rotation Angle: Approx. 270 °
type
7.5 cm (3.0-type) type TFT
Number of dots (total)
1 036 800 dots
Shutter
Shutter Type
Mechanical shutter / Electronic shutter
Shutter Speed
Still images (Mechanical shutter): 1/4000 to 30 s, Bulb, Still images (Electronic shutter): 1/8000 to 30 s, Movies: 1/8000 to 1 s
Flash Sync. Speed
1/160 s (35mm full frame), 1/200 s (APS-C) *With compatible Sony external flash.
Electronic Front Shutter Curtain
Yes
Weight/Size
Weight
679g
Dimensions
Approx. 129.7 x 77.8 x 103.7 mm, Approx. 129.7 x 77.8 x 85.0 mm (from grip to monitor)
