Type
Digital exposure meter for ambient and flash light
Receptor Head
Rotating Domed Head 90° to the right, 180° to the left, Retractable for Contrast Reading
Light Receiving Method
Incident light and reflected light
Receptor Incident Light
Dome retracts for contrast readings
Receptor Reflected Light
5° Viewfinder (Separate Accessory)
Light Receptor Element
2-Silicon photo diodes (incident and reflected)
Measuring Range and Modes
Measuring Modes Ambient Light
TF Priority
HD Cine - Shutter priority metering, FPS (Frame Rate Priority) metering, Lux/FC
Cine - FPS (Frame Rate Priority) metering, Shutter Angle setting, Lux/FC
Simple brightness measurement (foot-lambert, cd/m2
Simple illumination measurement (lux, foot-candle)
Aperture priority metering
EV metering
Shutter priority metering
Measuring Modes Flash
Without synchro cord (cumulative and non-cumulative)
With synchro cord (cumulative and non-cumulative)
Measuring Range (ISO 100) Ambient Light
Incident light EV-2 to EV 22.9
Reflected light EV3 to EV 19.9 (requires accessory sold separately)
Measuring Range (ISO 100) Flash
Incident Light f/1.0 to f/128.9
Reflected Light f/2.8 to f/128.9 (requires accessory sold separately)
Measuring Range Illuminance
0.63 to 2000000lux - 0.10 to 180000FC
Measuring Range Brightness
1 to 980000 cd/m2 - 0.29 to 290000 foot lamberts
Display Range and Modes
Display Range Film Speed
ISO 3 to 409600 (in 1/3 steps)
Display Range Shutter Speeds Ambient
30 min to 1/64,000 sec. (in 1, 1/2, 1/3 steps) plus 1/200, 1/400
Display Range Shutter Speeds Flash
30 min to 1/1000 sec. (in 1, 1/2, 1/3 steps) plus 1/75, 1/80, 1/90, 1/100, 1/200, 1/400
Display Range Aperture
f/0.5 to f/161.2 (in 1, 1/2, 1/3 steps)
Other
Battery(Power)
(2) Type AAA 1.5V Battery Alkaline, Manganese, Lithium, NiCad, NiMH, nickel types
