Drone
Takeoff Weight
<249 g (the takeoff weight includes battery and propeller blades)
Folded Size
88X143X58 mm
Unfolded Size(propeller blades included)
300X242X58 mm
Unfolded Size(propeller blades excluded)
210x152x58 mm
Diagonal Dimension
219mm
Max Speed(Sport Mode)
Ascent speed 5 m/s
Descent speed 4 m/s
Horizontal speed 16 m/s
Max Wind Speed Resistance
38 km/h(Level 5)
Maximum Flight Altitue
120 m
Max Takeoff Altitude
4000 m
GNSS
GPS + GLONASS + Galileo + BeiDou
Operating Temperature
0° ~40°
Operating Frequency
2.400 ~2.4835 GHz
Transmission Power
2.4 GHz: <20 dBm
Hovering Accuracy Range
Vertical: ±0.1 m (with Vision Positioning),
±0.5 m (with GNSS Positioning)
Horizontal: ±0.3 m (with Vision
Positioning),
±1.5 m (With GNSS Positioning)
Extra Payload
Not supported
Max Flight Time
32mins(measured at a speed of 5m/s in low-altitude, windless conditions)
Max Hovering Time
29mins(measured in indoor hovering)
Camera
Lens Tilt Range
+20°~ -90°
Image Sensor
1/3" 1/2"
Effective Pixel
48MP
ISO Range
Normal video mode: 100 - 6400 AI Night: 100 - 25600
Shutter Speed
1/24 s ~1/25000 s
FOV
79.4°
Aperture
F1.8
Photo Resolution
8000×6000 (4:3)
Image Format
JPG/JPG + RAW (DNG)
Video Resolution
4K: 3840×2160 (16:9)@24/25/30 fps
2.7K: 2704×2028 (4:3)/2704×1520 (16:9)/1520×2704
(9:16)@24/25/30 fps
FHD: 1920×1440 (4:3)/1920×1080 (16:9)/1080×1920
(9:16)@24/25/30/50/60 fps
Slow Motion: 1920×1080 (16:9)@2/3/4/5 x
Video Format
MP4(H.264)
Max Video Bitrate
80 Mbps
Supported File Formats
FAT32 (≤32 GB) exFAT (>32 GB)
Supported SD Card Type
microSD card (U3 or V30 rating or above)
Max Vertical Image Size
1520×2704 (9:6)
Still Photography Mode
Single shot JPG+RAW: 12 MP
BRK: 3/5 frames (12 MP+JPG)
Burst shooting: up to 7 frames (12 MP+JPG)
Interval timer shooting: 2/3/4/5/6/7/8/9/10/15/20/25/30 s (12 MP+JPG)
Panoroma: Wide angle, 180°, Vertical"
Color Mode
HDR
Defog Mode
Yes
Digital Zoom
4K: 1-2x, 2.7K: 1-3x, FHD: 1-4x
Intelligent Flight Mode
Pull-Away, Spiral, Rocket, Circle, Boomerang and Dolly Zoom
Tracking Modes
AI Track
Gimbal
Mechanical Range
Tilt: -125° to +45° Roll: ±45° Pan: ±30°
Controllable Range
/Tilt: -90° to +10° Roll: +35°
Max Control Speed(tilt)
100°/s
Angular Vibration Range
±0.01°
Downward Vision System
Hovering Range
0.3 - 5 m (ideal environment)
Available at 0.3 - 10 m
Visual Positioning Inoperative Scenarios
1. Monochrome surfaces, such as pure black or pure white.
2. Surfaces with strong reflections, such as smooth metal surfaces.
3. Transparent object surfaces, such as water or glass.
4. Surfaces of moving objects, such as running pets, grass blown by strong wind,
or above a crowd of people.
5. Scenes with dramatic changes in lighting, such as flying suddenly from indoors
to bright outdoor light.
6. Environments that are very dark or very bright.
7. Surfaces with highly repetitive textures or patterns, such as small tiles with the
same design.
8. Surfaces with highly uniform stripes.
Video Transmission
Video Transmission System
PixSync 4.0
Operating Frequency
2.402 ~2.4835 GHz
Transmitter Power(EIRP)
2.4 GHz, ≤ 20 dBm
Live View Quality
1080P @ 30fps
Latency
200ms
Max Transmission Bitrate
6 Mpbs
Max Transmission Distance
FCC: 10 km c
CE/SRRC: 6 km
Antenna
Dual antennas
Max Wi-Fi Download Speed
Wi-Fi 5 & 5 GHz: 25 MB/s
Remote Controller
Model
DSRC23A
Operation Frequency
2.402 ~2.4835 GHz
Max Transmission Distance(unobstructed, free of interference)
FCC: 10 km CE/SRRC: 6 km
Operting Temperature
0°C~40°C
Battery
5000 mAh, lithium-ion
Transmitter Power(EIRP)
2.4 GHz, ≤ 20 dBm
Charging Interface
USB-C
Charging Specification
USB-C, supporting up to 18W PD fast charge
Video Transimission System
PixSync 4.0
Video Transmission Quality
1080P
Latency
200ms
Supported Mobile Device Size
L: 170 mm W: 100 mm H: 12.5 mm
* For mobile devices with protruding rear cameras, the maximum supported thickness is 18 mm.
Supported Mobile Device Port Type
Lightning, USB-C, Micro-USB
* Using a mobile device with Micro-USB port requires the Standard Micro-USB connector, which is sold separately.
Smart Flight Battery
Model
DSBT02B
Capacity
2230 mAh
Voltage
7.7V
Battery Type
Li-Po 2S
Energy
17.18 Wh
Battery Weight
84g
Operating Temperature
0°C~40°C
Charging Method
1. USB-C (max 5V/3A)
2. Parallel Charging Hub (supports simultaneous charging for 3 batteries at 18W each)
Charging Environment Temperature
5°C to 40°C
Fastest Charging Time
1.3h With Parallel Charging Hub
