Recording Media
SD Memory Card (SDHC, SDXC, UHS-I, II compatible, Eye-Fi Card compatible)
Lens Mount
Micro Four Thirds
Image Sensor Size
17.3 mm x 13.0 mm
Sensor Type
4/3 Live MOS Sensor
Pixels
Effective pixels: Approx. 16.1 megapixels
Total: Approx. 17.2 megapixels
Image type
RAW (12-bit lossless compression), JPEG, RAW+JPEG, MPO(3D still)
Image Area (Pixels)
AW: 4608(H)x3456(V) (approx. 1/1.5 lossless compressed) Approx. 17MB
Set1(LF): 4608(H)x3456(V) (1/4 compressed) Approx. 7.5MB
Set2(LN): 4608(H)x3456(V) (1/8 compressed) Approx. 3.5MB
Set3(MN): 3200(H)x2400(V) (1/8 compressed) Approx. 1.7MB
Set4(SN): 1280(H)x960(V) (1/8 compressed) Approx. 0.4MB
Movie
1920x1080 (FHD) / 30p, 25p, 24p / ALL-I (A-I), IPB (SF,F,N)
1920x1080 (FHD) / 60p, 50p / IPB (SF, F, N)
1280x720 (HD) / 60p, 50p, 30p, 25p, 24p / ALL-I (A-I), IPB (SF,F,N)
AF Points
81-area multiple AF/ All target, group target area (9-area), single target(normal), single target(small)
Focusing Modes
Single AF (S-AF) / Continuous AF (C-AF) / Manual Focus (MF) / S-AF + MF / AF tracking (C-AF + TR)
Metering Range
EV -2 - 20 (using 17mm f2.8, ISO 100)
ISO Speed Range
AUTO ISO : LOW(approx. 100) ?__25600 (customizable, Defalut:LOW-1600)
Manual ISO : LOW(approx.100), 200 - 25600, 1/3 or 1 EV steps selectable
Shutter Speeds
Electronic shutter / 1/8000 - 8 sec.
Top Continuous Shooting Speed
Sequential shooting H mode: approx 10.0 fps (IS OFF, Focus and exposure are fixed at the values for the first shot.)
Battery
BLS-50 battery
Dimensions
123.7mm(W) x 85mm(H) x 44.5mm(D)
Weight
Approx. 469g (with BLS-50 battery and Memory card)
Approx. 417g (body only)
